K95
Firefighting TIC, 95° Wide-Angle Field of View, 640 × 480, App-Enabled
The Flir K95 is the next generation of the K-Series, designed to give firefighters a clearer, more complete view before, during, and after every incident. Combining 640 × 480 thermal resolution with an expansive 95° field of view, the K95 reveals more of the scene in every glance. By reducing the need for constant scanning and panning, it helps crews understand room layouts, identify movement paths, assess fire development, and make faster, better-informed decisions during search and rescue and fire attack.
Its single-gain solution provides continuous, freeze-free imaging without losing critical scene information. From overheated doors and hidden fire spread to floor openings, the K95 helps firefighters recognize changing conditions sooner, attack fires more strategically, and manoeuvre through smoke-filled environments with greater confidence. Wireless connectivity to the Flir Responder App also simplifies camera configuration, enables live video streaming for training, and supports mission data sharing after the call.
사양
| 강조 표시됨 | |
|---|---|
| 적외선 해상도 | 640 × 480 |
| 디스플레이 | 4" LCD, 640 × 480, 60 Hz, backlit |
| 대상 온도 범위 | Single range solution operating: -20°C to 650°C (-4°F to 1202°F) |
| 이미지 모드 | Basic, Search, Detection, High Heat, White Hot |
| 이미징 및 광학 | |
|---|---|
| 대비 최적화 | Flexible Scene Enhancement (FSX®) |
| 비 방사 측정(Non_radiometric) 적외선 동영상 녹화 | MPEG4 to internal flash memory |
| 비 방사선 측정(Non_radiometric) 적외선 동영상 스트리밍 | Uncompressed colorized video using USB and MPEG-4 Stream over Wi-Fi to Flir Responder app |
| 스펙트럼 범위 | 7.5µm to 14 µm |
| 시야각 (FOV) [시야각 (FOV)] | 95° × 74° |
| 열 감도_NETD | <70 mK |
| 이미지 모드 | Basic, Search, Detection, High Heat, White Hot |
| 이미지 주파수 | 30 Hz |
| 적외선 해상도 | 640 × 480 |
| 줌 | 2x digital zoom |
| 탐지기 유형 | Focal plane array (FPA), uncooled microbolometer |
| 피치 | 12 µm |
| 환경 및 인증 | |
|---|---|
| EMC | EN 301 489-1 RED
EN 301 489-17 EN 55032 Class B (Emission) EN 55035 (Immunity) EN 61000-6-2 Immunity according to Industrial EN 61000-6-3 380-480MHz EN 61000-6-3 800-960MHz EN 60945 Maritime equipment FCC 47 CFR part 15 B, cla |
| 낙하 | 2 m (6.6 ft) on concrete floor (IEC 60068-2-31) |
| 보관 온도 범위 | -40°C to 85°C (-40°F to 185°F) |
| 상대 습도 | 95% relative humidity 25°C to 40°C
(77°F to 104°F) non-condensing |
| 습도 [작동 및 저장] | IEC 60068-2-30/24 h 95 |
| 인캡슐레이션 | IP67 (IEC 60529) |
| 자기장 | EN 61 000-4-8, Test level 5 for continuous field (severe industrial environment) |
| 작동 온도 범위 | -20°C to 60°C (-4°F to 140°F)
150°C (302°F): 15 min 260°C (500°F): 5 min |
| 전파 스펙트럼 | ETSI EN 300 328
ETSI EN 301 893 FCC 47 CFR part 15 RSS-247 |
| 진동 | 2 g (IEC 60068-2-6) |
| 충격 | 25 g (IEC 60068-2-27) |
| 전력 | |
|---|---|
| 배터리 용량 | 5.8 Ah, at 20°C to 25°C (68°F to 77°F) |
| 배터리 유형 | Li-Ion |
| 배터리 작동 시간 | Approx. 4 hours @ 25°C (77°F) ambient temperature and typical use |
| 배터리 전압 | 3.7 V |
| 안전 [전원 공급] | CE/EN/UL/CSA/PSE 60950-1 IEC 62368 |
| 전원 관리 | For documents like MSDS and UN38.3 test reports/summaries, see: https://support.flir.com/resources/msds |
| 충전 시간 | ≤3 h to capacity enough for 3 h operation |
| 충전 시스템 | Desktop 2-bay charger
Optional in-truck charger |
| 충전 온도 | 0°C to 45°C (32°F to 113°F) |
| 측정 및 분석 | |
|---|---|
| 대상 온도 범위 | Single range solution operating: -20°C to 650°C (-4°F to 1202°F) |
| 일반 | |
|---|---|
| 패키지 포함 내역 | Infrared camera
Battery (2 ea.) Battery charger Carabiner strap Power supply Printed documentation Retractable lanyard, 16 N (58 oz) USB cable |
| 사용자 인터페이스 | |
|---|---|
| 디스플레이 | 4" LCD, 640 × 480, 60 Hz, backlit |
| 통신 및 데이터 저장 공간 | |
|---|---|
| USB | USB-C |
| WiFi | IEEE 802.11 b/g/n (2.4 GHz) |
| 블루투스 | Bluetooth v. 5.0 EDR + BLE *PAN |
| 이미지 저장 | Camera and Flir Responder app |
| 이미지 저장 용량 | 200 files in total (N.B. The total number of files varies dependent on the number of saved video clips) |
| 인터페이스 | Update via OTA (Wi-Fi using the Flir Responder app)
Legacy support for updates from PC and data transfer to and from PC |
| 저장 매체 | Internal flash memory |
| 파일 형식 | Standard JPEG |
액세서리
리소스 및 지원
Datasheet
FLIR K95 데이터시트
Warranty
FLIR Fire Service 2-5-10 Global Limited Warranty
Export Restrictions
The information contained in this page pertains to products that may be subject to the International Traffic in Arms Regulations (ITAR) (22 C.F.R. Sections 120-130) or the Export Administration Regulations (EAR) (15 C.F.R. Sections 730-774) depending upon specifications for the final product; jurisdiction and classification will be provided upon request.
